Page 612
A-298
SC140 DSP Core Reference Manual
MOVES.2F
The Ln bit is set in d0, and the number in d0 is positive (bit 39 = 0), so the saturated value $7FFF is written
to memory.
Instruction Formats and Opcodes
Instruction Fields
Da:Db
hh
Data Register Pairs
EA
MMM
Effective Address Notation
Rn
RRR
Address Register
SR
$00E0 0000
$00E0 0000
d0
$1:$00 8000 0000
d1
$0:$00 7EAC F00D
R0
$0000 0054
$0054
$7FFF
$0056
$7EAC
Instruction
Words Cycles Type
Opcode
15
8
7
0
MOVES.2F Da:Db,(EA)
1
1
2
1
0
*
0
0
1
h
h
1
0
1 M M M R R R
Notes:
1.
** indicates serial grouping encoding.
2.
When the form (Rn + N0) is used in EA, the cycle count is increased by 1.
00
D0:D1
01
D2:D3
10
D4:D5
11
D6:D7
Note:
This instruction can specify D8-D15 as operands by using a prefix.
000
(Rn+N0)
010
(Rn)
100
(Rn)+N0
110
(Rn)+N2
001
(Rn)–
011
(Rn)+
101
(Rn)+N1
111
(Rn)+N3
000
R0
010
R2
100
R4
110
R6
001
R1
011
R3
101
R5
111
R7
Note:
This instruction can specify R8-R15 as operands by using a high register prefix.
Register/Memory Address
Before
After
