OR
OR
Bitwise Inclusive OR (DALU)
OR
Description
Status and Conditions that Affect Instruction
None.
Status and Conditions Changed by Instruction
Example
or d3,d0
1110 ---- 0111 ---- 0101
or 0101 ---- 0011 ---- 1000
1111 ---- 0111 ---- 1111
Instruction Formats and Opcodes
Instruction Fields
Da
JJJ
Single Source Data Register
Operation
Assembler Syntax
Da
⏐ Dn → Dn
OR Da,Dn
OR Da,Dn
Performs a bitwise inclusive OR of two data registers (Da and Dn) and stores the result in the second data
register (Dn). This is a full 40-bit operation.
Register Address
Bit Name
Description
Ln
L
Clears the Ln bit in the destination registers.
Register/Memory Address
Before
After
D3
$E0 0007 0005
L0:D0
$0:$50 0003 0008
$0:$F0 0007 000F
Instruction
Words Cycles Type
Opcode
15
8
7
0
OR Da,Dn
1
1
2
1
1
0
1
1
1
F
F
F
0
0
1
1
J
J
J
000
D0
010
D2
100
D4
110
D6
001
D1
011
D3
101
D5
111
D7
Note:
This instruction can specify D8-D15 as operands by using a prefix.
