488
Router Protocols
Supported Protocols
NV Ethernet Ethernet connectivity between the NV9000 sys-
tem controller and all current Grass Valley routers
at 100MB/s. CAT5E patch cord. (Do not use
a crossover cable.)
NV Master Control
Ethernet Ethernet connection from the NV9000 system
controller to a Grass Valley master control sub-
system (NV5128-MC or NV5100MC) at 100MB/s. CAT5E patch cord. (Do not use
a crossover cable.)
NV Compact Router
Ethernet Ethernet connection from the NV9000 system
controller to all Grass Valley compact routers
(such as the CR1616-HD and CR3232-AES) at
100MB/s.
(This protocol is UDP.)
CAT5E patch cord. (Do not use
a crossover cable.)
Virtual Router Use this protocol to emulate a router using Grass
Valley’s NV Ethernet protocol.
This protocol is useful for developing a configura-
tion without an actual router.
(Status is lost every time the NV9000 is restarted.)
(None required.)
Utah RCP-1 An NVISION router can operate under a Utah con-
trol system using this protocol.
A properly configured Utah AVS2, SC1, SC2 or
PL320 controller is required.
Cabling depends on the Utah
controller model.
Jupiter ESBus An NVISION router can operate under a Jupiter
control system using this protocol.
A properly configured VM3000 controller is
required.
Operation using a serial port on an SI-3000 is not
recommended if the total controlled matrix space
exceeds 256 × 256.
DE9 crossover (or null
modem) cable required.
GVG Horizon TCI An NVISION router can operate under a GVG Hori-
zon control system using this protocol.
An HX-GPI external controller running TCI proto-
col is required.
Please note the NV9000’s control point settings
for Horizon: S, ‹COM port›, 9600 baud, no parity, 8
data bits, 1 stop bit.
DE9 cable with non-standard
pinout.
Probel Router An NVISION router can operate under a Probel
control system using this protocol. Varies by application. Consult
the Probel documentation.
Pesa An NVISION router can operate under a Pesa con-
trol system using this protocol.
A properly configured Pesa controller is required.
This connection is RS-232 using one of the ports
on the Pesa controller that is normally reserved
for the Pesa configuration PC. Pesa does not sup-
port an RS-422 interface.
DE9, with RS-232 pins Tx, Rx,
and ground (typically pins 2, 3
and 5).
The Pesa end must be wired
for RS-232 loopback.
Connect RTS to CTS and DTR
to DSR.
ISIS Serial An NVISION router can operate under an ISIS con-
trol system using this protocol. DE9 wired straight through.
Protocol Description Cable
