296
Control Panels
NV9646
Button Types
These are the button types:
Back Broadcast Category Chop
Clear Preset Default State Destination Destination Lock
Destination Protect Free Source [Forward] Global Navigate
Hold Information Level Map Menu
Name Set Toggle Navigate Page Down Page Up
Panel Lock Preset Release Previous Source Quick Source
Salvo Save Preset Selection Source
Source Master Source/Destination Take Toggle Display
VFD/SEL Toggle X-Y Display XY/MD Mode
‘Edit Navigation Button’ Dialog
During configuration, when you choose ‘Navigate’ for a selected button, NV9000-SE Utilities
displays a dialog in which you specify the navigation button’s details:
At the top, this dialog presents 3 lines on which you can enter text for the button caption.
Automatic Fill Options
Button text
Navigation
Choices
