212
Control Panels
‘Add SW Panel’ Page
‘Previous’ Button
Click the ‘Previous’ button if you want to go to the previous page in the panel definition
sequence.
‘Next’ Button
Click ‘Next’ to go to the panel configuration page. In this page, you specify the details of the
software panel.
‘Finish’ Button
Click ‘Finish’ to accept the panel thus far defined in the ‘Add SW Panel’ page.
The panel definition, as specified in the ‘Add SW Panel’ page is incomplete. You must later go to
the panel configuration page to complete the definition.
This button allows you to create a number of panel configurations rapidly and complete them
later.
After you click ‘Finish’, the ‘Add SW Panel’ page remains and is re-initialized for additional entries.
‘Cancel’ Button
Click ‘Cancel’ if you want to terminate the panel definition you started.
When you click ‘Cancel’, the ‘Add SW Panel’ page re-initializes for another entry.
Basic Information
There are 3 fields in the basic information section:
These are the basic information fields:
• Type
Select a software panel type in the drop-down list of the ‘Type’ field.
• Computer (or Windows User) Name where panel will be located
Examine system parameters of the Windows system of the PC on which the GUI that uses
this configuration resides. Either obtain the system name or the Windows user name of the
user that will use the panel. Enter either name in the text field.
 When the corresponding panel is installed, its installation option “per-user or per-
computer” must match the entry you choose in this configuration.
• User
Choose a user name from the drop-down list of this field. (It is this user name that is reported
when the panel’s operator locks or protects sources or destinations.)
