140
Devices and Device Categories
Devices Page
Filters
At the top of the page are 2 filters:
•
Device Filter. If you enter text in this field, the list of devices is restricted to those devices
whose names contain the text you entered.
•
Level Set Filter. If you select a level set in the drop-down list of this field, the list of devices is
restricted to those devices that belong to the level set selected.
(If you choose ‘All’
—
assuming that is not the name of a level set you defined
—
the category
list is not restricted.)
Device List
The device list has 3 columns:
•
ID. These are the database IDs of the different devices.
•
Device. These are the names of the devices.
•
‘Level Set’. A field in this column identifies the level set to which the corresponding device
belongs.
You can use click, shift-click, and control-click techniques to select any of the devices in the list.
Buttons
‘Edit Selected Devices’ Button
This button opens a device details page for each of the devices you have selected in the list. It is
in the device details page that you specify the I/O ports of the device.
See
‘Add Device’ Button
This button causes NV9000-SE Utilities to display the ‘Add Device’ page. The ‘Add Device’ page
starts a device definition.
See
