NV9000-SE Utilities
User’s Guide
available through the navigation button. A “back” button is a good candi-
date for such a button.
Check box
“Use custom button text.” Check this box if you want to override the
button’s default text. This checkbox is not present for all button types.
When you choose a button type, additional drop-down menus can appear, depending on the
button type, allowing you to further specify the button’s behavior. Available options and selec-
tions vary from button type to button type.
The Navigate button is unique: during configuration, it initiates a dialog in which you create a
subtree. During operation, it switches the panel to the button page associated with the button.
See
‘Edit Navigation Button’ Dialog
Some buttons that are generated dynamically during operation.
There are different sets of button types for global suffix pages and for global navigation pages.
See
Button Types
These are the button types available for NV9642 configurations:
Back
Broadcast
Category
Chop
Clear Preset
Default State
Destination
Destination Lock
Destination Protect
Free Source
[Forward]
Global Navigate
Hold Information
Level
Map
Menu
Name Set Toggle
Navigate
Page Down
Page Up
Panel Lock
Preset Release
Previous Source
Quick Source
Salvo
Save Preset
Selection
Source
Source Master
Source/Destination
Take
Virtual Level Contract
Virtual Level Expand XY Display
XY/MD Mode
Note that other panels might have button types with the same names but that perform
different functions.
