224
Control Panels
NV9602
 Clicking a local salvo has no effect. Control-clicking a system salvo likewise has no effect.
When you click a system salvo, the following dialog appears:
Select a system salvo from the drop-down menu. If the salvo was already in the salvo list, you
can delete it from the list.
When you click a local salvo, the following dialog appears:
To create a local salvo, enter or re-enter the name of a local salvo in the text box. If the local salvo
exists already, you can delete it from the NV9601’s salvo list.
After you create a local salvo, it is empty. It contains no commands. It is the task of the panel
operator to create or erase the contents of a local salvo by recording actions at the panel. (Local
salvo definition is a function available when the panel is in menu mode.)
NV9602
NV9602 Panel Description
The NV9602 is a 1RU panel. It has 2 sets of backlit function buttons and a small display. The
display has 2 distinct LED readouts each having 8 characters:
The NV9602 can operate in one of 4 modes. See Modes of Operation , following.
An equivalent virtual panel — the NV9602V — is available.
The function buttons select sources or destinations, or they execute functions.
The up and down arrows at the far right apply only when the panel is in menu mode.
Display Function
Buttons Function Buttons
