226
Control Panels
NV9602
The panel’s set of button functions varies with the mode.
The modes (or behavioral models) are determined at configuration. The operator cannot switch
between different modes.
The NV9604 control panel can operate as an extension of the NV9602. See
Single-Destination Mode
In single destination mode, the panel’s destination is configured as the default destination and
there are no destination buttons. Takes occur as soon as a source button is pressed. (There is no
‘Take’ button function.)
Takes are performed on all levels.
Single-Destination Mode with Breakaway
This mode is an extension of single-destination mode that includes level buttons on the panel.
Again, the single destination is configured as the default destination. There are no destination
buttons and there is no ‘Take’ button.
Limited X-Y Mode
In limited X-Y mode, takes occur from a single source to a single selectable destination.
Takes are all level. Pressing a source button completes the take. There is no ‘Take’ button.
Multi-Destination Mode
In this mode, source buttons are configured with destinations as well as sources. Thus, each
source button completes a route to an individual destination.
There is no ‘Take’ button. Takes are all-level.
Secondary Modes
Additional but secondary modes of panel operation are:
•
Setup mode
—
where the NV9602 is freshly powered up, but disconnected from the net-
work. In this mode, you can set the panel ID and perform a few diagnostic tasks.
•
Menu mode
—
pressing a menu button places the NV9602 in “menu” mode. In menu mode,
the buttons lose their normal functions and become part of a menu that changes as needed
during menu operation.
•
Source mode
—
(in limited X-Y mode only) allows ‘Source/Destination’ buttons to select
sources.
•
Destination mode
—
(in limited X-Y mode only) allows ‘Source/Destination’ buttons to select
destinations.
Other NV9602 Functions
The NV9602 can perform the following additional functions:
•
System salvos.
•
Broadcast data routing.
