383
NV9000-SE Utilities
User’s Guide
‘Finish’ Button
Click ‘Finish’ to accept the external interface thus far defined in the ‘Add External Interface’ page.
The external interface definition, as defined in the ‘Add External Interface’ page is incomplete.
You must later go to the
External Interface Details Page to complete the definition.
This button allows you to create a number of external interface definitions rapidly and complete
them later.
After you click ‘Finish’, the ‘Add External Interface’ page remains and is re-initialized for addi-
tional entries.
‘Cancel’ Button
Click ‘Cancel’ if you want to terminate the external interface definition you started.
When you click ‘Cancel’, the ‘Add External Interface’ page re-initializes for another entry.
External Interface Details Page
The external interface details page is not called “external interface details” in NV9000-SE Utili-
ties. An external interface details page appears either when you select an external interface for
editing in the ‘External Interface’ page, when you click ‘Next’ in the ‘Add External Interface’ page,
or when you click ‘Edit’ in the ‘Apps Table’ page.
This is a typical external interface details page:
Interface
Information
Control
Point
Information
