8 Manual control
viva 1.0 (for Process analysis)
￭￭￭￭￭￭￭￭ 877
Output signal
Current status
Shows the current status of the 14 output lines.
Templates/Entry
Entry of the bit pattern for the output signal or selection of a predefined
signal pattern.
It is possible to enter the following characters:
0 = line inactive
1 = line active
* = any line status
p = set pulse (pulse length = 1 s. If a pulse with a different length is to be
output, then a corresponding template must be defined for this purpose.)
Sample changers
Selection
Bit pattern with exactly 14 characters (0, 1, *,
p) | ************** | signal pattern
Default value **************
894
Selection
Bit pattern with exactly 14 characters (0, 1, *,
p) | ************** | signal pattern
Default value **************
Spectrometer
Selection
Bit pattern with exactly 10 characters (0, 1, *,
p) | ********** | signal pattern
Default value **********
The output lines and bits are numbered from right to left:
Output 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Bit 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Examples:
************1* sets the output line 1 to active (= set).
************0* sets the line to inactive.
