5 Method
viva 1.0 (for Process analysis)
￭￭￭￭￭￭￭￭ 557
Functions
Moves the selected line up.
Moves the selected line down.
[New]
Opens the Digital output # dialog window in order to edit a new line
(see Chapter 5.5.2.11.2.4, page 557).
[Properties]
Opens the Digital output # dialog window in order to edit the selected
line (see Chapter 5.5.2.11.2.4, page 557).
[Delete]
Deletes the selected line.
5.5.2.11.2.4 DIGITAL OUT - Digital output #
Dialog window: Method ▶ DIGITAL OUT ▶ Properties... ▶ DIGITAL OUT - 'Com-
mand name' ▶ Digital outputs ▶ [Properties] ▶ DIGITAL OUT - Digital output #
Port description
Selection of the digital output. The digital outputs of the selected instru-
ment are available. No port can be selected if not defined is selected in
the Device name field.
Type
Shows the digital output type.
Function
Action
Selection On | Off | Timer | Set default value
Default value Timer
On
Sets the digital output to On after expiration of Start delay.
Off
Sets the digital output to Off after expiration of Start delay.
Timer
Sets the digital output to On after expiration of Start delay and back
again to Off after expiration of Working time.
Set default value
Resets the digital output to the default value in the configuration.
