44-41
(*,G) Entries: 1
(S,G) Entries: 0
(S,G,rpt) Entries: 0
(*, 239.192.1.10)
RP: 10.1.6.1
RPF nbr: 10.1.4.10
RPF idx: Vlan1
Upstream State: JOINED
Local ..l.............................
Joined ................................
Asserted ................................
Outgoing ..o.............................
Displayed Information Explanations
Entries The counts of each item
RP Share tree’s RP address
RPF nbr RP direction or upneighbor of source direction.
RPF idx RPF nbr interface
Upstream State Upstream State, there are two state of Joined(join
the tree, expect to receive data from upstream)
and Not Joined(quit the tree, not expect to receive
data from upstream), and more options such as
RPT Not Joined, Pruned, Not Pruned are available
for（S,G,rpt.）
Local Local join interface, this interface receive
IGMPJoin
Joined PIM join interface, this interface receive J/P
messages
Asserted Asserted state
Outgoing Final outgoing of multicast data, in this example,
the index of the outgoing interface is 2. Command
“show ip pim interface” can query interface
information.
44.3.36 show ip pim neighbor
