66-2
<session>: session ID, range between 1~7. <vid>: The id of RSPAN VLAN.
Command Mode:
Global Mode.
Default:
Not configured.
Usage Guide:
To configure local mirror session to RSPAN. The VLAN id is the RSPAN VLAN. The mirrored data
grams will be attached with RSPAN tags.
Example:
Switch(config)#monitor session 1 remote vlan 5
66.3 monitor session reflector-port
Command:
monitor session <session> reflector-port
no monitor session <session> reflector-port >
Function:
To configure reflector port, the no form of this command will delete the reflector port.
Parameter:
<session>: Session ID, range between 1~7, <interface-number>: Interface number.
Command Mode:
Global Mode.
Default:
Not configured.
Usage Guide:
This command configures the reflector port for the destination of mirror data grams, and disables
the MAC learning function of the specified port. The configuration of reflector port is to change the
mode of the local port from the destination port mode to be the reflector mode. Hence, the
configuration of reflector port and the destination port are exclusive. The no command is used to
restore the reflector port to normal port. The source port, in access or trunk mode, should not be
added to RSPAN VLAN. When the reflector port is configured as springboard of CPU TX direction
mirroring, it must be configured as TRUNK port and allows the RSPAN VLAN data passing, the
Native VLAN should not be configured as RSPAN VLAN.
Example:
Switch(config)#monitor session 1 reflector-port ethernet1/0/3
