62-7
62.11 mrpp ring secondary-port
Command:
mrpp ring < ring-id > secondary-port
no mrpp ring < ring-id > secondary-port
Function:
Specify secondary of MRPP ring.
Parameter:
is the ID of MRPP ring; range is <1-4096>.
Command Mode:
Port mode
Usage Guide:
The command specifies secondary port of MRPP ring. The primary node uses secondary port to
receive Hello packet from primary node. There are no difference on function between primary port
and secondary of secondary node.
The mrpp enable command must be enabled before the control-vlan command be used. If primary
port, secondary port, node-mode and enable commands all be configured after control-vlan, then the
mrpp-ring function is enabled.
Example:
Configure secondary port of MRPP ring to 1/0/3.
Switch(config)#interface ethernet1/0/3
Switch(Config-If-Ethernet1/0/3)#mrpp ring 4000 secondary-port
62.12 node-mode
Command:
node-mode {maser | transit}
Function:
Configure the type of the node to primary node or secondary node.
Command Mode:
MRPP ring mode.
Default:
Default the node mode is secondary node.
Example:
Configure the switch to primary node. MRPP ring 4000.
Switch(config)# mrpp ring 4000
