14-120
Switch(config)#spanning-tree mst configuration
Switch(Config-Mstp-Region)#show mst-pending
Name switch
Revision 0
Instance Vlans Mapped
----------------------------------
00 1-29, 31-39, 41-4093
03 30
04 40
05 4094
----------------------------------
Switch(Config-Mstp-Region)#
14.2.3 show spanning-tree
Command:
show spanning-tree [mst []] [interface ] [detail]
Function:
Display the MSTP Information.
Parameter:
sets interface list; sets the instance ID. The valid range is from 0 to
64; detail sets the detailed spanning-tree information.
Command mode:
Admin and Configuration Mode
Usage Guide:
This command can display the MSTP information of the instances in the current bridge.
Example:
Display the bridge MSTP.
Switch#sh spanning-tree
-- MSTP Bridge Config Info --
Standard : IEEE 802.1s
Bridge MAC : 00: 03: 0f: 01: 0e: 30
Bridge Times : Max Age 20, Hello Time 2, Forward Delay 15
Force Version: 3
