9-18
in “on” mode is a “forced” action, which means the local end switch port aggregation does not rely
on the information of the other end, port aggregation will succeed as long as all ports have
consistent VLAN information. Adding a port in “active” or “passive” mode enables LACP. Ports of at
least one end must be added in “active” mode, if ports of both ends are added in “passive” mode,
the ports will never aggregate.
Example:
Under the Port Mode of Ethernet1/0/1, add current port to “port-group 1” in “active” mode.
Switch(Config-If-Ethernet1/0/1)#port-group 1 mode active
9.9 show port-group
Command:
show port-group [] {brief | detail |}
Function:
Display the specified group number or the configuration information of all port-channel which
have been configured.
Parameters:
is the group number of port channel to be displayed, from 1 to 128;
brief displays summary information;
detail displays detailed information.
Command mode:
All Configuration Mode.
Usage Guide:
If the user does not input port-group-number, that means the information of all the existent
port-group are showed; if the port channel corresponds to port-group-number parameter and is not
exist, then print a error message, otherwise display the current port-channel information of the
specified group number.
Example:
1. Display the summary information of port-group 1.
Switch# show port-group brief
ID: port group number; Mode: port group mode such as on active or passive;
Ports: different types of port number of a port group,
the first is selected ports number, the second is standby ports number, and
the third is unselected ports number.
ID Mode Partner ID Ports Load-balance
