LonMaker User’s Guide 263
Monitoring Enabled Text is black.
Monitoring Disabled Text is magenta.
The LonMaker tool updates the style of the connection shapes, as required, if changes are made to the
connections that affect the service type used.
Generating a Device Status Summary Report
You can generate a status summary report listing the devices and routers that are unconfigured and
offline, and selected functional blocks that are in the override, alarm, or disabled states or have
reported communication or self-test failures. For a functional block to be listed in the report, it must be
associated with a device that is configured and online.
To generate a status summary report, follow these steps:
1. Open the LonMaker menu and click Device Status Summary. The Device Status Summary
Options dialog box opens.
2. Select the scope of the Device Status Summary and the types of functional blocks to include in the
report.
Scope Select the scope of the Device Status Summary Report. This
determines which applicable application devices, routers, and
functional blocks will be included in the report. You have three
