Chapter 3: How to Certify Twisted Pair Cabling
Settings for Twisted Pair Tests
73
HDTDR/HDTDX Fail/Pass* only: The tester shows HDTDR and HDTDX
analyzer results only for Autotests with PASS*, FAIL*, or
FAIL results.
All Autotests: The tester shows HDTDR and HDTDX
analyzer results for all Autotests.
To get HDTDR/HDTDX analyzer results you can also tap
Tools > Diagnostics.
For more information about the HDTDR and HDTDX
analyzers, see Chapter 5.
Outlet
Configuration
The Outlet Configuration specifies which wire pairs are
tested and which wire numbers the wire map shows for the
pairs. See Figure 26.
To see the wire map for a configuration, tap Outlet
Configuration, tap the configuration name on the OUTLET
CONFIG screen, then tap SAMPLE.
To select a configuration, tap a name on the OUTLET
CONFIG screen, then tap USE SELECTED.
Note
The OUTLET CONFIG screen shows only the
configurations that are applicable to the
selected Test Limit.
AC Wire Map The AC Wire Map test lets you do tests on links connected
through midspan PoE (Power over Ethernet) devices. See
Chapter 4.
When the AC Wire Map test is on, this icon shows on the
home screen:
Note
Always turn off the AC wire map test when you
will not do tests through a PoE device. The AC
wire map test increases the time for an
Autotest.
Table 2. Settings for Twisted Pair Tests (continued)
