Chapter 2: Get Started
Tutorial: Do a Bi-Directional OTDR Test
45
Tutorial: Do a Bi-Directional OTDR Test
The tutorial in this section gives instructions on how to set up for
a bi-directional OTDR test, set up the launch compensation
function, make connections, do a test, and save the results.
Figure 15 shows the equipment necessary for this tutorial.
Figure 15. Equipment for the OTDR Tutorial
GPU52.EPS
Main Versiv unit with OptiFiber
Pro module installed
Launch and tail cords (match the
fiber to be tested)
Fiber cleaning supplies
Fiber link or segment
AC adapter with line cord
(optional)
A
B
D
C
E
