Chapter 7: How to Certify Fiber Cabling
Autotest in Smart Remote Mode
189
GPU145.EPS
Figure 84. Unsaved and Saved Result for Smart Remote Mode
Unsaved
bi-directional result.
Saved bi-directional result
for the output fiber.
Fiber 01-B-B-00 was
connected to the INPUT port
at the start of the test
Saved bi-directional
result for the input
fiber
Unsaved
uni-directional result
Saved uni-directional
result for the input
fiber
Saved uni-directional
result for the output
fiber
Uni-Directional Results
Bi-Directional Results
