Chapter 5: How to Diagnose Copper Test Failures
How to Use the Measurement Cursor on the HDTDR and HDTDX Plot
143
How to Use the Measurement Cursor on the
HDTDR and HDTDX Plot
You can use the cursor on the HDTDR and HDTDX plots to
measure the distance to a source of high return loss or crosstalk
from any point on the plot. You can also measure the length of a
segment or patch cord that causes high return loss or crosstalk.
To use the measurement cursor to measure distance
Refer to Figure 69.
1
Tap the yellow circle at the top of the cursor (
) so that MARK
shows.
2
While MARK shows, use one of these methods to move the
cursor to the point where you want to start the measurement:
Drag the cursor with the yellow circle (
).
Tap or press and hold
or
(
).
3
Tap MARK, then while UNMARK shows, move the cursor to
the point where you want to end the measurement.
Note
If UNMARK and the cursor controls do not show,
tap the yellow circle.
The distance between the cursor and the mark shows below the
plot (
).
4
To make a new measurement, tap the yellow circle, tap
UNMARK (
), then do steps 1, 2, and 3 again.
