OTDR Results
Notes
The tester shows measurements with “>” or “<“
when the actual value is possibly more or less than
the value shown. For example, this can occur for
hidden events or for measurements that are out
of the range of the tester.
When a test is completed, the type of screen the
tester shows first (EventMap, TABLE, or TRACE) is
the type you looked at last.
EventMap
Notes
The EventMap combines the results for all
wavelengths used for the test. If an event on the
EventMap does not show on the event table or
OTDR trace, change the wavelength on those
screens.
The EventMap does not show ghosts.
Refer to Figure 107:
 The ID for the results. If Auto Save is off, Result not saved
shows.
 The end of the fiber.
 The length of the fiber segment between two events.
 A reflective event:
: A reflective event, which is usually a connector.
Measurements for the event are all within the test limits.
: One or more measurements for the event exceeds the limit.
 : Launch and tail cords and their connectors show in gray. The
map shows these if Launch Compensation is on and the cords
are connected.
