Chapter 9: How to Use the OptiFiber Pro OTDR Module

OTDR Results

253

Gainer
An apparent gain in the
strength of the returned
signal. A gainer shows
as a negative value of
loss. Page 297 shows
OTDR traces gainers.

Caused by a splice or connection between two

fibers that have different backscatter

coefficients, numerical apertures, core diameters,

or mode field diameters.
The tester compares the loss of non-reflective

gainers to the limits for splice loss to give the

event a PASS/FAIL status.
If a gainer occurs at a connection, the gainer

shows as a Reflection event with negative loss.

The tester compares reflective gainers to the

limits for reflective events to give the event a

PASS/FAIL status.
Strong reflections at or before an event can

cause tailing after the event, which can cause a

measurement of negative loss.
To find the cause of a gainer, see if the fiber type

is different before and after the splice or

connection. Replace fiber if necessary. Fibers that

are the same can possibly have different

tolerances, which can cause gainers at a splice.

When this occurs, the splice is usually good and

does not require rework.
If you do the OTDR test from the other end, the

gainer event will show a loss. If you add this loss

to the gain from the other direction, you get the

true loss of the event. If you upload the results to

LinkWare software, you can use the bi-

directional averaging utility in LinkWare to

calculate the true loss of gainers.
Gainers at launch events can occur when the

launch cord does not have the same properties as

the fiber under test. In this situation, you can get

more reliable results if you do a bi-directional

test and calculate the true loss as described

above. Use a tail cord that has the same

properties as the launch cord and use Launch +

Tail compensation.

(continued)

Table 11. Event Types (continued)
