Versiv Cabling Certification Product Family
Technical Reference Handbook
370
DSX-5000 CableAnalyzer Module
Specifications
Tests and Frequencies Supported
DSX-5000 Modules
 TIA Cat 3, 4, 5, 5e, 6, 6A, 7 certification per TIA 568-C.2
 ISO/IEC Class C and D, E, E
A
, F, F
A
certification per ISO/IEC
11801:2002 and amendments
 Maximum frequency: 1200 MHz
Times for a Full, 2-Way Autotest
Category
Autotest Time 1,2,3
Cat 5e or 6/Class D or E < 9 seconds
Cat 6
A
/Class E
A
< 10 seconds
ISO 11801 PL Class E (includes TCL)
< 15 seconds 4
Cat 7/Class F or F
A
< 15 seconds
Class F
A
, All tests
< 30 seconds 5
1. On unshielded cable. Autotests on shielded cable take approximately 0.6 seconds
longer.
2. The first Autotest after power-on takes approximately 1.5 seconds longer. If the
Autotest includes common-mode measurements, add 0.8 seconds more.
3. AC wire map function adds approximately 3 seconds to Autotest times.
4. Also applicable to any Cat 6/Class E Autotest with common-mode measurements.
5. Also applicable to any Class F/F
A
Autotest with common-mode measurements.
