Jumper Reference
:
Enter the number of jumpers you will use in
each fiber path when you set the reference. The dotted lines in
the diagram on the screen show you which parts of the link are
included in the test results. See Reference Method on page 173.
The dotted lines show you which parts of the link are included in
the test results.
Connector icons show the connections between the ends of the
link. If you enter 7 or more for the Total Connections setting, a
number inside of a connector icon shows the number of
connectors between the ends of the link. For example, if the
Total Connections setting is 7, a connector icon shows the
number 5 (
)
The round icon shows the number of splices in each path of the
link.
To see help for the screen, tap
.
To save your settings, tap DONE.
