TCL (Transverse Conversion Loss)

Transverse conversion loss is the ratio (in dB) of a common-mode

voltage measured on a wire pair relative to a differential-mode

voltage applied to the same end of the pair. The TCL value shows

you how well the impedances of the pair’s conductors are balanced.

A high TCL value means that the impedances of the conductors

relative to ground are almost equal. High TCL values correspond to

better noise immunity and lower emissions.

Differential and Common-Mode Signals

To increase noise immunity and decrease the emissions of twisted

pair cabling, network equipment transmits and receives signals in

differential mode. Differential-mode uses two signals that have

equal amplitudes and opposite polarities. The transmitter applies

one signal to each wire in a pair, and the receiver measures the

voltage between the wires. Because the voltages on the two wires

have equal amplitudes and opposite polarities, the electromagnetic

fields around the wires cancel each other out. The twisting of the

pairs improves the cancellation. Because the pair emits almost no

electromagnetic radiation, it causes almost no noise in other wire

pairs.
Differential-mode signaling also reduces electrical noise on the pair

from outside sources such as electric motors and nearby pairs.

Electromagnetic fields from outside sources cause voltages that have

the same amplitudes and polarities on each wire in the pair. These

are common-mode voltages. Because the difference in the noise

voltage between the wires is zero, the receiver rejects common-

mode signals, and the noise does not show in the network signals on

the pair (Figure 57, top).

Effects of Unbalanced Impedance in a Wire Pair

If the wires in a pair have unequal impedances to ground, the

common-mode voltages induced on the pair by nearby

electromagnetic fields converts to differential-mode noise that

interferes with the data signal. (Figure 57, bottom).
Conversely, an unbalanced pair radiates unwanted electromagnetic

radiation. This occurs because the opposing, differential signals are

not equal, so the they are partially converted to common mode.

Common-mode power on a wire pair produces more radiation than
