Versiv Cabling Certification Product Family
Technical Reference Handbook
140
GPU114.EPS
Figure 67. HDTDX Plot
To zoom in and out, use the pinch, reverse-pinch, and double-
tap gestures on the touchscreen. You can also use the zoom
controls to change the magnification on the distance and
amplitude scales independently. See Figure 5 on page 18.
Note
For HDTDX plots for short cables such as patch
cords, the tester does not change the magnification
for the distance (horizontal) scale.
B
D
A
E
G
F
C
