Versiv Cabling Certification Product Family
Technical Reference Handbook
378
HDTDX Analyzer Specifications for Cables <100 m (328 ft)
The specifications below are typical for cables less than 
100 m (328 ft).
HDTDR Analyzer Specifications for Cables <100 m (328 ft)
The specifications below are for HDTDR tests on cables less than
100 m (328 ft) long.
Characteristic Impedance
The tester gives an estimate of the cable's impedance at 
4 m from the start of the link. The accuracy of the measurement is
relative to a 100  terminating resistance.
Parameter Twisted Pair Cable
Distance accuracy  (1 ft (0.3 m) + 2 % distance)
Distance resolution 1 ft or 0.1 m
Parameter Twisted Pair Cable
Distance accuracy  (1 ft (0.3 m) + 2 % distance)
Distance resolution 1 ft or 0.1 m
Parameter Twisted Pair Cable
Range 70  - 180 
Accuracy ± (5  + 5 % of 100  – Measured)
Resolution 1 
