Figure 136. Typical Dead Zone Performance of Multimode
OptiFiber Pro Modules
0
1
2
3
4
5
6
7
-55
-50
-45
-40
-35
-30
-25
-20
Dead
Zone
(mete
rs
)
Connector Reflectance (dB)
1300
nm
Att
enu
atio
n De
ad Z
one
850 nm
Atten
uation
Dead
Zone
850 nm/1300 nm Event Dead Zone
