Versiv Cabling Certification Product Family
Technical Reference Handbook
388
Visual Fault Locator
DI-1000 Video Probe
On/off control Mechanical switch and a button on the
touchscreen
Output power (into SM fiber
with SC/UPC connector) 316 µw (-5 dBm) peak power 1.0 mW
(< 0 dBm)
Operating wavelength 650 nm nominal
Spectral width (RMS)  3 nm
Output modes Continuous wave and pulse mode (2 Hz to 3 Hz)
Connector adapter 2.5 mm universal
Laser safety Class II CDRH over operating temperature
range
Complies to EN 60825-2
Magnification 200X with OptiFiber Pro display
Light source Blue LED
Connection to OptiFiber Pro
tester USB type A plug
Power source Power supplied by the main Versiv unit
Field-of-view (FOV) Horizontal: 425 µm
Vertical: 320 µm
Minimum detectable
particle size <0.5 µm
Dimensions Approximately 6.75 in long x 1.5 in diameter
(1175 mm x 35 mm) without adapter tip
Weight 7 oz. (198 g)
Temperature range Operating: 32 °F to 122 °F (0 °C to +50 °C)
Storage: -4 °F to +158 °F (-20 °C to +70 °C)
Certifications

(when used with the main Versiv unit)
