Event Table
The event table shows a list of the events on the fiber. To see the
event table, tap TABLE on the OTDR results screen. Figure 109
shows an example of an event table. Table 11 gives descriptions
of the event types.
GPU12.EPS
Figure 109. Event Table
 To see details for an event, tap the event in the table. Scroll the
table if necessary to see all the events.
 (ft) or (m): The distance to the event
 LOSS: The loss of the event.
 REFLECT: The reflectance of the event.
A
B
E
F
D
C
