Chapter 17: Specifications
Summary of Performance Specifications
375
Table 20. Level V Accuracy Performance Parameters
per IEC Guidelines
Parameter Baseline Field Tester
Field Tester with
Level V
Permanent Link
Adapter
Field Tester with
Level V Channel
Adapter
Dynamic
range 3 dB over test limit
PPNEXT and FEXT 65 dB
PS NEXT and FEXT 62 dB
Amplitude
resolution 0.1 dB
Frequency
range and
resolution 1 MHz to 31.25 MHz: 150 kHz
31.25 MHz to 100 MHz: 250 kHz
100 MHz to 250 MHz: 500 kHz
250 MHz to 600 MHz: 1 MHz
600 – 1,000 MHz: 2 MHz
Dynamic
Accuracy
NEXT ± 0.75 dB
Dynamic
Accuracy
ACR-F ± 1.0 dB (FEXT dynamic accuracy is tested to ± 0.75 dB)
Source/load
return loss 1 MHz to 300 MHz: 
20 – 12.5 log(f/100), 
20 dB maximum
300 MHz to 600 MHz:
14 dB
600-1,000 MHz: 
21-9 log(f/100) 1- 300 MHz: 18 – 12.5 log(f/100),
20 dB maximum
300 MHz to 600 MHz: 12 dB
600-1,000 MHz: 19-9 log(f/100)
Random
Noise Floor 95 dB 90 dB
-continued-
