Chapter 9: How to Use the OptiFiber Pro OTDR Module
OptiFiber Pro Connectors, Keys, and LEDs
219
 LCD display with touchscreen.
 Singlemode OTDR port with interchangeable SC adapter and
protective cap. The LED in front of the port turns on when the
port emits an optical signal.
 Multimode OTDR port with interchangeable SC adapter and
protective cap. The LED in front of the port turns on when the
port emits an optical signal.
 Visual fault locator port and protective cap. The LED in front of
the port turns on when the port emits an optical signal.
 Warning 
Do not look directly into optical connectors. Some
sources emit invisible radiation that can cause
permanent damage your eyes.
 Button that controls the VFL.
 Micro-AB USB port: This USB port lets you connect the tester to a
PC so you can upload test results to the PC and install software
updates in the tester.
 Type A USB port: This USB host port lets you save test results on a
USB flash drive or connect a video probe to the tester.
 Headset jack.
  : Starts a test. To start a test, you can also tap TEST on the
display.
  : Power key.
  : Press  to go to the home screen.
 Connector for the ac adapter. The LED is red when the battery
charges, and green when the battery is fully charged. The LED is
yellow if the battery will not charge. See “Charge the Battery”
on page13.
 RJ45 connector: For functions available in future software
releases.
