Chapter 17: Specifications
CertiFiber Pro OLTS Module Specifications
379
CertiFiber Pro OLTS Module Specifications
CertiFiber Pro Power Meter Specifications
Input connector Interchangeable connector adapter 
(LC standard)
Detector type InGaAs
Wavelengths 850 nm, 1310 nm, 1490 nm, 1550 nm, 1625 nm
Power measurement
range 850 nm: +10 dBm to -65 dBm
All other wavelengths: +10 dBm to -70 dBm
Display resolution dB, dBm: 0.01
Linear (nW, µW, mW): 0.001 to 9.999, 10.00 to 99.99,
100.0 to 999.9 depending upon value
Display update rate 1 reading per second
Power measurement
uncertainty (accuracy)  5 %  32 pW 1,2
Measurement linearity <  0.1 dB 3
Re-calibration period 1 year
1. 100 pW at 850 nm
2. Under the following conditions:
 Power level 100 µW (-10 dBm), continuous wave (CW) for absolute power at
850 nm and 1310 nm.
 Divergent beam, NA = 0.20 for 50/125 µm and NA = 0.14 for 9/125 µm.

Ambient temperature 23° ± 1 °C.

SC/UPC connector with ceramic ferrule.
 After a 5 minute warm-up.
 Traceable to NIST.
3. -3 dBm to -55 dBm at 850 nm and 1310 nm. Ambient temperature 23 °C ± 1 °C. 
After a 5 minute warm-up.
