gpu139.eps

Figure C-4. Modified 1 Jumper Reference and Test Connections for Smart

Remote Mode

*Use mandrels only with multimode modules.



Caution

Do not disconnect the
outputs (

and

) after

you set the reference.

Short MT-RJ (no pins)

to MT-RJ (pinned)

test reference cord

(0.3 m or less.

Fiber Link Test

Reference

Mandrel*
