Versiv Cabling Certification Product Family
Technical Reference Handbook
12
GPU147.EPS
Figure 2. Versiv Remote Unit Connectors, Keys, and LEDs
PASS LED comes on when a test passes.
TEST LED comes on during a test.
FAIL LED comes on when a test fails.
TALK LED comes on when the talk function is on (see
). To
adjust the volume, press or the button on the headset’s
microphone.
