AT-FS970M Switch Command Line User’s Guide
327
The field “Gateway of last resort is” states the default gateway, which, if
defined on the switch, is also included as the first entry in the table.
The possible codes in the left column in the table are described in Table
30.
Note
RIP routes have an additional option which indicates the time lapsed
in hours: minutes: seconds since the RIP entry was added. See
Figure 73.
The elements of the static and RIP routes are identified in Figure 73.
Figure 73. Static and RIP Route Elements
Table 30. Route Codes in the SHOW IP ROUTE Command
Code Description
S* Default gateway.
R Route to a remote network learned by RIP.
S Static route to a remote network.
C Local network of a routing interface.
149.101.33.0/24 [1/0] via 149.101.23.28, vlan15, 00:05:27 R
Next Hop Remote Network VLAN of
Next Hop
Administrative
Distance
Metric/Cost
S - Static
R - RIP
Elapsed Time
hours:minutes:seconds
(RIP Routes Only)
