AT-FS970M Switch Command Line User’s Guide
1751
Figure 268. SHOW MLS QOS INTERFACE Command - Strict Priority
(continued)
Figure 269 is an example of a port set to Weighted Round-Robin
scheduling.
Figure 269. SHOW MLS QOS INTERFACE Command - WRR
Egress Queue: 6
Scheduler: Strict Priority
Weight: N/A
Egress Queue: 7
Scheduler: Strict Priority
Weight: N/A
CoS: 0
Queue: 2
Number of egress queues: 8
Egress Queue:
0
Scheduler: Weighted Round Robin
Weight: 1
Egress Queue: 1
Scheduler: Weighted Round Robin
Weight: 1
Egress Queue: 2
Scheduler: Weighted Round Robin
Weight: 5
Egress Queue: 3
Scheduler: Weighted Round Robin
Weight: 5
Egress Queue: 4
Scheduler: Weighted Round Robin
Weight: 10
Egress Queue: 5
Scheduler: Weighted Round Robin
Weight: 10
Egress Queue: 6
Scheduler: Weighted Round Robin
Weight: 15
Egress Queue: 7
Scheduler: Weighted Round Robin
Weight: 15
