Chapter 104: Routing Information Protocol (RIP)

1840

Displaying Routing Information with RIP

To confirm that routes are dynamically added by RIP, use the SHOW IP
RIP command.

S1# show ip rip

Figure 283 is an example of the information the command displays.

Figure 283. SHOW IP RIP Command

The columns in Figure 283 are defined in Table 257 on page 1876.

Codes: R - RIP, Rc - RIP connected, Rs - RIP static

C - Connected, S - Static

Network Next hop Metric From If Time

Rc 10.10.10.0/24 1 vlan10

Rc 10.10.50.0/24 1 vlan50

C 192.168.99.0/24 1 vlan1

R 192.168.20.0/24 10.10.10.32 10.10.10.3 vlan10 00:00:19

The R indicates that this network entry is added through RIP.
