AT-FS970M Switch Command Line User’s Guide
1753
SHOW MLS QOS MAPS COS-QUEUE
Syntax
show mls qos maps cos-queue
Parameters
port
Specifies the port to display. You can view only one port at a time.
Mode
Privileged Exec mode
Description
Use this command to display the mappings of CoS priority values to
egress queues. See Figure 270 for an example of the default mapping.
Figure 270. SHOW MLS QOS MAPS COS-QUEUE Command
The CoS values in the first line are matched with the egress queue
assignments in the second line. For example, in Figure 270, port 1 packets
with CoS 0 are placed in egress queue 2, packets with CoS 1 are placed in
egress queue 0, and so on.
The mappings of CoS priorities and egress queues are set with “MLS QOS
MAP COS-QUEUE” on page 1716.
Example
This example displays the mappings of CoS priority values:
awplus# show mls qos maps cos-queue
COS-TO-QUEUE-MAP:
COS: 0 1 2 3 4 5 6 7
----------------------------
QUEUE: 2 0 1 3 4 5 6 7
