Chapter 9: Port Parameters
196
Figure 49. SHOW INTERFACE Command
The fields are described in Table 13 on page 230. For a description of the
command, see “SHOW INTERFACE” on page 229.
Displaying Port
Configuration
To display the current port configuration settings, use the SHOW
RUNNING-CONFIG INTERFACE command in the Privileged Exec mode.
Here is the format:
show running-config interface interface-list
This example displays the settings for ports 1 and 2:
awplus# show running-config interface port1.0.7
See Figure 50 for an example of the display.
Figure 50. SHOW RUNNING-CONFIG INTERFACE Command
For a description of the command, see “SHOW RUNNING-CONFIG
INTERFACE” on page 240.
Interface port1.0.1
Link is UP, administrative state is UP
Address is 0015.77cc.e243
index 1 mtu 9198
SNMP link-status traps: Enabled (Suppressed in 0 sec.)
Bandwidth 1g
input packets 0, bytes 0, dropped 0, multicast packets 0
output packets 0, bytes 0, multicast packets 0 broadcast packets 0
Interface port1.0.2
Link is UP, administrative state is UP
Address is 0015.77cc.e244
index 2 mtu 9198
SNMP link-status traps: Enabled (Suppressed in 0 sec.)
Bandwidth 1g
input packets 0, bytes 0, dropped 0, multicast packets 0
output packets 0, bytes 0, multicast packets 0 broadcast packets 0
Interface port1.0.7
switchport
switchport mode access
switchport access vlan 2
