Chapter 103: IPv4 Routing Commands
1828
Note
RIP routes have an additional option which indicates the time lapsed
in hours: minutes: seconds since the RIP entry was added. See
Figure 279.
The elements of the static and RIP routes are identified in Figure 279.
Figure 279. Static and RIP Route Elements in the SHOW IP ROUTE
Command
Example
This example displays the routes on the switch:
awplus# show ip route
S Static route to a remote network.
C Local network of a routing interface.
Table 253. Route Codes in the SHOW IP ROUTE Command (Continued)
Code Description
149.101.33.0/24 [1/0] via 149.101.23.28, vlan15, 00:05:27 R
Next Hop Remote Network VLAN of
Next Hop
Administrative
Distance
Metric/Cost
S - Static
R - RIP
Elapsed Time
hours:minutes:seconds
(RIP Routes Only)
