AT-FS970M Switch Command Line User’s Guide
1803
Example of the Routing Commands
This section contains an example of the commands of the IPv4 routing
feature. The example has the following sections:
 “Creating the VLANs” on page 1803
 “Creating the Routing Interfaces” on page 1804
 “Adding Static and Default Routes” on page 1806
 “Activating RIP” on page 1808
The switch in the example has four local networks in separate VLANs. The
table below lists the relevant information.
Creating the
VLANs
The first step is to create the VLANs for the local networks on the switch.
The VLANs must be created before the routing interfaces. The following
series of commands creates a VLAN for the Sales department with the
VID 4 and the appropriate ports:
Table 250. IPv4 Routing Example
Company
Group
VLAN
Name
VID
Network IP
Address
Subnet Mask
IP Routing
Interface
Address
Switch
Ports
1
Sales Sales 4 149.35.67.0 255.255.255.0 149.35.67.11 U: 1-11
T: 50
Production Production 5 149.35.68.0 255.255.255.0 149.35.68.24 U: 12-20
T: 50
Engineering Engineering 11 149.35.69.0 255.255.255.0 149.35.69.23 U: 21 - 30
T: 50
Inventory Inventory 15 149.35.70.0 255.255.255.0 149.35.70.45 U: 31 - 40
T: 50
1. U - untagged ports; T - tagged ports
awplus> enable Enter the Privileged Executive
mode from the User Executive
mode.
awplus# configure terminal Enter the Global Configuration
mode.
awplus(config)# vlan database Enter the VLAN Configuration
mode.
