Chapter 99: Quality of Service (QoS) Commands
1748
SHOW MLS QOS AGGREGRATE-POLICER
Syntax
show mls qos aggregate-policer name
Parameters
name
Specifies the name of the aggregate policer.
Mode
Privileged Exec mode
Description
Use this command to display the settings of all aggregate policers
configured on the switch. To set a single-rate police aggregate, see “MLS
QOS AGGREGATE-POLICE SINGLE-RATE” on page 1707. To set the
twin-rate police aggregate, see “MLS QOS AGGREGATE-POLICE TWIN-
RATE” on page 1710.
Figure 266 displays an example of the output of the SHOW MLS QOS
AGGREGATE-POLICER command.
Figure 266. SHOW MLS QOS AGGREGATE-POLICER
See Table 237 on page 1749 for a description of the field listed in
Figure 266.
Note
The definitions for the single-rate and twin-rate policers are different.
AGGREGATE-POLICER-NAME: ap1
Policer single-rate action drop-red:
average rate (125 kbps) minimum burst (125 B) maximum burst (1024B)
AGGREGATE-POLICICER-NAME: COP
Policer single-rate action policed-dscp-tx:
average rate (1 kbps) minimum burst (3B) maximum burst (4B)
maximum rate (2 kpbs)
AGGREGATE-POLICICER-NAME: policytwin
Policer twin-rate action drop-red:
minimum rate (500 kbps) maximum rate (1200 kpbs) minimum burst (3 B)
maximum burst (4B)
