Chapter 98: Quality of Service (QoS)
1652
The following example uses the SET QUEUE command to set the traffic
classified by class map “cmap4” to queue 6 within policy map “pmap3:”
Egress Queue
Shaping
In addition to setting egress port queues, you may want to configure
egress queue shaping to further refine the queues. This section discusses
how to set the following values on an egress queue:
 Bandwidth transmission rate
 Scheduling method
 Transmission limit
Table 218. Using the SET QUEUE Command
Command Description
awplus> enable Enters the Privileged Executive mode
from the User Executive mode.
awplus# configure
terminal Enters the Global Configuration mode.
awplus(config)# mls qos
enable Activates the QoS feature on the
switch.
awplus(config)# class-map
cmap4 Creates a class map called “cmap4”
and enters the Class Map mode.
awplus(config-cmap)# exit Exits the Class Map mode.
awplus(config)# policy-
map pmap3 Creates a policy map called “pmap3.”
awplus(config-pmap)#
class cmap4 Adds class map “cmap4” to policy map
“pmap3.”
awplus(config-pmap-c)#
set queue 6 Sets traffic classified by class map
“cmap4” to queue 6.
