AT-FS970M Switch Command Line User’s Guide
261
Displaying PoE Information
The switch allows you to display PoE information using three commands.
Each command displays a different set of PoE information as described in
Table 22.
This example displays PoE information on both the switch and all the ports
on the switch:
awplus# show power-inline
Figure 60 shows an example of the information the command displays.
The columns are described in Table 24 on page 283.
Figure 60. SHOW POWER-INLINE Command
Table 22. PoE Show Commands
Command Description
SHOW POWER-INLINE Displays PoE information about the switch
and all the ports on the switch.
SHOW POWER-INLINE
COUNTERS Displays the PoE event counters for the
ports.
SHOW POWER-INLINE
INTERFACE Displays PoE information of specified ports.
SHOW POWER-INLINE
INTERFACE DETAIL Displays detailed PoE information of the
specified ports.
PoE Status:
Nominal Power: 490W
Power Allocated: 346.0W
Actual Power Consumption: 151.0W
Operational Status: On
Power Usage Threshold: 80% (392W)
PoE Interface:
Interface Admin Pri Oper Power(mW) Device Class Max(mW)
port1.0.1 Enabled Low Powered 3840 Phone#1 1 4000 [C]
port1.0.2 Enabled High Powered 6720 n/a 2 7000 [C]
port1.0.3 Enabled Low Powered 14784 n/a 3 15400 [C]
port1.0.4 Enabled Crit Powered 14784 n/a 3 15400 [C]
port1.0.5 Enabled Crit Powered 3840 Phone#2 1 4000 [C]
port1.0.6 Enabled High Powered 6720 n/a 2 7000 [C]
port1.0.7EnabledLowPowered14784n/a315400 [C]
