AT-FS970M Switch Command Line User’s Guide
1673
Figure 259. SHOW MLS QOS MAPS DSCP-QUEUE Command
Displaying DSCP
to Policed-DSCP
Values
To display the mapping between the existing DSCP value and the new
DSCP value, use the SHOW MLS QOS MAPS POLICED-DSCP
command. You can configure this mapping with the MLS QOS MAPS
POLICED-DSCP command. (For more information about this command,
see “MLS QOS MAP POLICED-DSCP” on page 1638.)
DSCP-TO-QUEUE-MAP:
---------------------
Queue: 0
DSCP: 0-7
---------------------
---------------------
Queue: 1
DSCP: 8-15
---------------------
---------------------
Queue: 2
DSCP: 16-23
---------------------
---------------------
Queue: 3
DSCP: 24-31
---------------------
---------------------
Queue: 4
DSCP: 32-39
---------------------
---------------------
Queue: 5
DSCP: 40-47
---------------------
---------------------
Queue: 6
DSCP: 48-55
---------------------
---------------------
Queue: 7
DSCP: 56-63
---------------------
