AT-FS970M Switch Command Line User’s Guide
1697
MATCH MAC-TYPE
Syntax
match mac-type <12bcast|12mcast|12ucast>
Parameters
l2bcast
Specifies the Layer 2 Broadcast frames as the MAC type.
l2mcast
Specifies the Layer 2 Multicast frames as the MAC type.
l2ucast
Specifies the Layer 2 Unicast frames as the MAC type.
Mode
Class Map mode
Description
Use this command to set the destination MAC type as a matching criteria
for a class map.
Note
All three parameters, l2bcast, l2mcast, and l2uncast, start with the
letter “l” and the number “2” to represent Layer 2.
Use the no form of this command, NO MATCH MAC-TYPE, to remove a
MAC type from a class map.
Confirmation Command
“SHOW CLASS-MAP” on page 1744
“SHOW RUNNING-CONFIG” on page 166
Examples
The following example sets the class map’s MAC type to Layer 2
broadcast frames:
awplus> enable
awplus# configure terminal
awplus(config)# class-map cmap1
awplus(config-cmap)# match mac-type l2bcast
