Chapter 11: Power Over Ethernet
262
This example displays the PoE information of port 1 through port 4:
awplus# show power inline interface port1.0.1-port1.0.4
Figure 61 shows an example of the information the command displays.
The columns are described in Table 24 on page 283.
Figure 61. SHOW POWER-INLINE INTERFACE Command
This example displays the detailed PoE information of port 10:
awplus# show power inline interface port1.0.10 detail
Figure 62 shows an example of the information the command displays.
The columns are described in Table 26 on page 288.
Figure 62. SHOW POWER-INLINE INTERFACE DETAIL Command
Interface Admin Pri Oper Power Device Class Max(mW)
port1.0.1 Disabled Low Disabled 0 n/a 0 15400 [C]
port1.0.2 Enabled High Powered 3840 Desk Phone 1 5000 [U]
port1.0.3 Enabled Crit Powered 6720 AccessPoint 2 7000 [C]
port1.0.4 Disabled Low Disabled 0 n/a 0 15400 [C]
Interface port1.0.10
Powered device type: Desk Phone #1
PoE admin enabled
Low Priority
Detection status: Powered
Current power consumption: 00 mW
Powered device class: 1
Power allocated: 5000 mW (from configuration)
Detection of legacy device is disabled
Powered pairs: Data
